Commander for Fiat- Lancia- Alfa Romeo -FCA

AVDI for Fiat/Lancia/Alfa/FCA is an advanced diagnostic software application designed to work together with the AVDI Vehicle Diagnostic Interface to perform basic and advanced diagnostics in Fiat, Lancia and Alfa vehicles. It provides full module identification for the Fiat Chrysler Automobiles vehicles as well, it allows diagnostic trouble code reading and clearing, also the ability to perform actuator tests in order to determine the cause of an electrical or mechanical fault. The diagnostic functions provided allow it to be on par with OEM diagnostic equipment while applying the intuitive and simplistic approach typical for the AVDI diagnostic software. AVDI diagnostics software allows the user to work with almost 100% of the vehicles by Fiat, Alfa Romeo, Lancia and models from the FCA Group (Fiat, Alfa, Chrysler, Dodge and Jeep including models built after 2013).

It is very important to note that the software covers vehicles from the full range of the FCA automotive group. This includes not just FIAT vehicles but also all American brands under the FCA name - Dodge, Chysler, Jeep. We provide support for all these cars up to 2018.

Standard diagnostics

• Reading and clearing of diagnostic trouble codes
• Module identification
• Data Display
• ECU Identification
• ECU Configuration
• Sensors
• Bussed Inputs
• Bussed Outputs
• LIN Data
• Line Graph
• Actuators
• Miscellaneous functions



Commander for Ford/Mazda

The AVDI for Ford/Mazda is a diagnostic software application, used together with AVDI (Abrites Vehicle Diangnostics Interface), that allows the user to perform standard and advanced diagnostics for Ford and Mazda vehicles.

GENERAL DIAGNOSTICS

Standard diagnostics include functions such as reading, identification and clearing of diagnostic trouble codes, module identification, extended module identification, service interval reset, actuator tests and many others.

The above described functions are standard features of the Abrites diagnostics for Ford/Mazda. They allow the user to determine the cause of an issue as well as provide assistance in repairing problems with the vehicles.

The advanced diagnostic functionality of the Abrites diagnostics for Ford/Mazda allows the user to perform key learning, module exchange and cluster calibration using new and used parts in a quick and comprehensible manner. The list of supported models is constantly being updated and currently includes almost every model.

The software is quick, easy and agile, and by being such it manages to exceed the user's expectations and provide a diagnostic level higher than the main dealer tools every time.

Standard diagnostic functions:

• Device scanning
• Reading identification data for all electronic control units
• Reading/clearing diagnostic trouble codes (DTCs) for all electronic control units
• Data Display/Measured values
• Fuel Injector Correction Factors
• Speed Limiter - Modify the speed limit set by the dealer on Ford Transit MK6(2000-2006) and MK7(2006+)
• Set RPM Controller mode and associated engine speed - Ford Transit MK6(2000-2006) and MK7(2006+)
• Programmable Module Installation - With PMI you can safely replace an original ECU with a used or a new one. PMI transfers the internal data from the original ECU to the replacement one. If the original ECU is not available, you can obtain the data from the Ford Global database.
• Reading and updating the EEPROM of the following RCM (airbag modules) of the following 95320/95640 types by OBD:
  - AM5T-14B321-xx, BM5T-14B321-xx, CM5T-14B321-xx ( Bosch / 95320) - Ford Focus 2010+
  - DM5T-14B321-xx, DV4T-14B321-xx, FJ5T-14B321-xx ( Bosch / 95640)
  - CV4T-14B321-xx ( Bosch / 95640)- Ford Kuga 2013+
  - CJ5T-14B321-xx ( Bosch / 95640) - Ford Escape
• DPF regeneration for the following engine types in the following vehicles:
  - 1.4 TDCI - Ford Fiesta 2008, 2010, 2013
  - 1.6 TDCI - Ford Focus/CMax 2011, 2015
  - 1.8 TDCI - Ford Focus/CMax 2011, 2015, Mondeo/SMax/Galaxy 2007, 2011,2015
  - 2.0 TDCI - Mondeo/SMax/Galaxy 2007, 2011
  - 2.2 TDCI - Mondeo/SMax/Galaxy 2007, 2011
  - 2.4 TDCI - Transit 2006, 2010, 2013
• GEM configuration Ford Focus/CMax MK2 - 2003, 2008. The function allows the adding of a cruise control module to vehicles that were not equipped with such from the factory.
• Ford/Mazda PCM Read/Write flash memory for the following ECUs:
  - EDC16C3 - 1.4/1.6 TDCI, EDC16C34 - 1.4/1.6 TDCI
  - SID804 - 1.8/2.0 TDCI
  - SID206 - 1.8/2.0 TDCI
  - Denso 1MB - Mazda 5/6 - 2.0D
• Service functions:
• PATS initialization for all models up to 2018 with the exception of FIESTA 2018.
  Reset The Powertrain Control module ( PCM ) Learned values
  Reset The Exhaust Gas Temperature value
  Initialize the Exhaust Gas Related component
  Reset Keep Alive Memory ( KAM )
  Reset the Diesel Particulate Filter ( DPF ) Learned Values
  Reset the Water in Fuel ( WIF ) Warning Indicator
  Reset the Knock Sensor Learned Values
  Reset the Fuel Metering Valve Learned Values
  Reset the Intake Air Throttle Valve Learned Values
  Reset the Exhaust Gas Recirculation ( EGR ) Valve Learned Values
  Reset the Differential Pressure Sensor Learned Values
  Fuel Injector Correction Factors
  Relearn Vehicle Data
  Reset the Mass Air Flow ( MAF ) Sensor Learned Values
  Reset the Fuel Pressure Relief Valve Open Count Learned Value
  Reset the Fuel Pressure Relief Valve Open Duration Learned Value
• VID (Vehicle Identification) - When looking at the European Ford Motor Company models built before and around 2005 we can see that most of the vehicle equipment configuration is stored in the engine control unit under VID. These configurations contain optional vehicle equipment such as electric windows, central locking, high-end audio systems, cruise control and others.
  The VID is used in the US market Ford vehicles, in some cases even with the later models. Using this function you can perform upgrades to the vehicles. For example you could upgrade a car with no cruise control to accommodate this option and accept it as if it was built in from the factory
• CCC (Central Car Configuration) - In many vehicles built after 2005, mostly European specification ones, the above mentioned VID receives an update - the philosophy behind it has changed.
  The more modern system receives the name CCC and performs a similar task in a much more optimized manner. You can perform upgrades and downgrades to the vehicle specification and add or remove optional components in such a way, that this does not affect the vehicle's performance in any way. A noteworthy fact is that the CCC is now contained in the Body Control Module, rather than the Engine Control Unit
• PMI (Programmable Module installation) - Using this option you can perform ECU exchange for various models. Our list of supported vehicle models is constantly growing and you can always see it under the special function, dedicated to the PMI

SPECIAL FUNCTIONS

Commander for Renault/Dacia

 GENERAL

GENERAL DIAGNOSTICS

The Abrites Diagnostics for Renault/Dacia is an extremely capable tool comparable in functionality to the original testers offered by manufacturers. Every unit has the same set of actuators and live data options that is provided by the official software but the information is presented in a much more convenient and understandable way allowing the user to quickly see the data they require in order to solve the problem at hand. Furthermore, the user can observe various parameters simultaneously (either numerically or graphically) without limitations to the number of parameters.

Below, you will be able to find a list of some of the most important and commonly used features of the Abrites Diagnostics for Renault/Dacia (online software):

. Module identification - an extremely important and powerful tool while performing basic diagnostics. The Abrites Diagnostics for Renault/Dacia performs the module identification automatically after choosing the vehicle model
. Reading and clearing of diagnostic trouble codes (DTCs) - this includes complete information about the errors in the module as per the available data as well as the ability to clear it (necessary after the fault has been eradicated).
. Display of actual values - this allows the user to monitor all available parameters reported by the vehicle's sensors hence giving the user the ability to provide a more accurate diagnostic procedure. Various parameters can be observed simultaneously (either numerically or graphically) without limitation to the number.
. Actuator testing - another helpful feature to aid the user to determine where the fault occurs. ALL actuators can be tested separately.
. Advanced diagnostics: The function provides extensive diagnostic data and configuration options.

. General diagnostics updated to support the latest models such as Clio V.

MODULE RENEWAL

The module renewal special function allows the user to return an already used module to factory state condition ready to be adapted to a new vehicle. The software then also allows the adaptation of the renewed modules (different procedures for the various modules). This function can be performed to the following modules:

• Airbag
  AB82 for Clio II Ph2
  AB90 for Clio III, Modus
  Autoliv for Laguna III, Clio III, Modus
  Continental T4 for Logan II, Sandero II, Lodgy, Twingo III, Clio IV
  Continental for Megane III, Laguna III, Fluence, Latitude
  Continental for Twingo II, Kangoo II
  Temic for Logan, Duster, Clio II, Symbol
  Autoliv Airbag Clear Crash for Talisman, Megane IV, Scenic IV, Espace V, Kadjar
• EPS for Clio III/IV, Megane III, Modus, Twingo III, Scenic III - the renewed module will adapt itself after installation in a new vehicle and turning the ignition on.
• Electronic Steering Lock (ESL) for Laguna III (ph1/2), Latitude, Megane III, Scenic III and Clio IV - the renewed module can be adapted to the recipient vehicle by using the PIN Code of the UCH of the donor vehicle.
• Radio – calculation of renewal code from PRECODE
• Handsfree module and UCH for Clio IV as well as for the following models:

Module renewal

The module renewal special function allows the user to return an already used module to factory state condition ready to be adapted to a new vehicle. The software then also allows the adaptation of the renewed modules (different procedures for the various modules). This function can be performed to the following modules:

• Airbag

1. AB82 for Clio II Ph2
2. AB90 for Clio III, Modus
3. Autoliv for Laguna III, Clio III, Modus
4. Continental T4 for Logan II, Sandero II, Lodgy, Twingo III, Clio IV
5. Continental for Megane III, Laguna III, Fluence, Latitude
6. Continental for Twingo II, Kangoo II
7. Temic for Logan, Duster, Clio II, Symbol

• EPS for Clio III/IV, Megane III, Modus, Twingo III, Scenic III - the renewed module will adapt itself after installation in a new vehicle and turning the ignition on.
• Electronic Steering Lock (ESL) for Laguna III (ph1/2), Latitude, Megane III, Scenic III and Clio IV - the renewed module can be adapted to the recipient vehicle by using the PIN Code of the UCH of the donor vehicle.
• Radio – calculation of renewal code from PRECODE
• Handsfree module and UCH for Clio IV as well as for the following models:


  Clio II	Clio III*	Dokker*
  Duster Ph2*	Espace IV*	Kangoo
  Laguna II*	Laguna III*	Latitude*
  Lodgy*	Logan*	Logan II*
  Master	Master II	Megane II*
  Megane III*	Modus*	Sandero
  Sandero II*	Scenic II*	Scenic III*
  Symbol	Trafic	Trafic III*
  Twingo III*	Velsatis*

  *The renewed UCH can be adapted to the vehicle using the AVDI and a simple guided procedure.

ELECTRONIC MODULE PROGRAMMING

This function has been specifically developed to aid our customers when they are having problems with reflashing a certain module or want to transfer the configuration data from one module to another (e.g. instrument cluster). It is dedicated to:

• Reading/writing FLASH - used to recover a module if there has been a problem while reflashing. The software DOES NOT begin reflashing procedure before creating a backup of the current flash in the module. (This is saved on the customer's computer)
• Reading/writing ConfData - used to transfer configuration data and/or coding from one module to another. The most common case the procedure is used is when a customer has to exchange a faulty instrument cluster
• Recovering of Smart 453
• Virgin Engine Control Module (ECM) adaptation for Clio IV, Twingo III, Trafic III, Logan II, Sandero II, Duster Ph2, Dokker, Lodgy



KEY PROGRAMMING

- NEW! SMART 453 and Twingo III key programming even when all keys are lost! (RR019 and PROTAG needed).

- KEY and remote control programming for MEGANE IV (2016+

- NEW!- Renault Traffic III ALL KEYS LOST!!!

The key programming special function allows users to read the PIN code and subsequently program a key to the vehicle. The users can program both key cards and metal-cut keys and can program keys even in ALL KEYS LOST situations. The software also visualizes information about the keys currently programmed in the vehicle. The following models are supported for key learning:

SUPPORTED MODELS:

Instrument cluster recalibration

This special function allows the user to recalibrate the mileage in all relevant modules. For some models you can disable the dashboard synchronization with the ABS, recalibrate the mileage in the ABS or reset it to 0. These options are described in the supported models section.

Supported models:

• Talisman, Megane IV, Scenic IV, Espace V, Kadjar - mileage recalibration in both the instrument cluster and ATE ABS/ESC - by OBDII ( no reflashing necessary)
• Clio IV, Captur including disabling the synchronization with the ABS module or ABS mileage reset
• Twingo III, Trafic III, Smart 453 monochrome display
• Dacia Logan II, Sandero II, Lodgy, Dokker, Duster ph2 dashboards including disabling the synchronization with the ABS module or ABS mileage reset
• Laguna III, Megane III, Fluence (including disabling the synchronization with the ABS module or mileage recalibration in the ABS module)
• Megane II, Clio III, Master III, Kangoo II, Trafic II ph3
• Scenic/Modus (2003-2004), Clio II, Kangoo
• Clio/Kangoo/Megane with HC908 JAEGER instrument clusters (calibration is performed by connecting directly to the cluster using a dash connector)

Commander for Chrylser /Dodge / Jeep

AVDI Diagnostics for Chrysler/ Dodge/ Jeep is a diagnostic software application designed to work together with AVDI in order to perform basic and advanced diagnostics on Chrysler, Dodge and Jeep vehicles.

N.B.Since the introduction of the AVDI diagnostics for FCA the functionality of the AVDI diagnostics for Chrysler/ Dodge/ JEEP has been transfered to it also.

GENERAL DIAGNOSTICS

In terms of basic diagnostics, the ABRITES Diagnostics for Chrysler/Dodge/Jeep can connect to the devices using KWP2000, CAN and UDS over ISO transport protocol (CAN); The software allows reading and clearing of diagnostic trouble codes, module identification, extended ID, module detection, live data monitoring, testing and many other features available exclusively though our software.

Special functions:
