Supported Models:
Device supporting all TOYOTA/LEXUS/MAZDA/SUBARU/SUZUKI 2018-2025 cars with the
type of Smart Key Module listed below :
* TMLF18Dx DENSO (with Key HTAES 4A-AA) (!NEW!)
* TMLF19Tx TOKAI RIKA (with Key HTAES 4A-BA)
* TMLF19Dx DENSO (with Key DSTAES 8A-B9 and 8A-BA):
TOYOTA LEXUS MAZDA SUZUKI/SUBARU
* Aygo X - LBX 2023… - Mazda2 2023… - SWACE 2018..
* bZ4X - LM 2023… - SOLTERRA 2023…
* Camry 80 - LX 2021… - ACROSS 2021…
* C-HR PHV - NX 2021…
* Corolla Cross - GX550 2023…
* Corolla E21 2018… - RX 2022…
* Highlander 2023 - RZ 2022…
* Land Cruiser 250 - UX 2023…
* Land Cruiser 300
* Prius 2023
* RAV4 PHV
* Sequoia 2023
* Sienna HV
* Tundra 2021
* Yaris Cross
* Yaris 2018..
* Hilux 2024…
* Including the new unsupported modules TMLF19D(8A-B9/BA) and TMLF19T(4A-BA) from 2025…
Functionality:
Submenu “TOYOTA”:
1. “Read ECU & Open” - Read IMMO Data from smart key module by CAN BUS, unlock
car and disarm car Alarm. Data can be saved to 1 of 10 Car Data Files. Time around 5 seconds.
After selecting this function need to choose first correct type of 3 car modules:
1: TMLF19D 8A-B9/A
* Use this for all other cars than in pos 2 and 3. This work for cars with 8A-B9,8A-BA (DST-AES) keys.
2: TMLF19T 4A-BA
* Use this for Corolla 2021.., Yaris 2021.., Hilux 2024…, Mazda2 2023.., Aygo X. This work for cars with 4A-
BA(HT-AES) keys.
3: TMLF18D 4A-AA
Use this for Suzuki Swace, Corolla, Yaris 2018..2021. This Work on cars with 4A-AA keys.
Important Notice:
In most of 2026 and some 2025 vehicles, Toyota has introduced additional security measures. To use a special mode for reading data from the Smart Key module (such as the one used by this tool), the ignition must be turned on with a programmed key. In such vehicles, the device displays an error code of "Error Code 1-22."
However, some 2026 cars working ok , without ignition on or valid key. Because new passwords for accessing the TMLF19T and TMLF19D modules have been added to the device,
Automatic type recognition had to be replaced with manual selection of the Smart Key module type. If the
TMLF19D type is used instead of the TMLF19T, or vice versa, the Smart Key module will temporarily block access
to the data reading function. In such a situation, the device returns an error code: "Error Code 2-37" and in
order for the device to work even in the correct mode, you must wait a few minutes or disconnect the power
supply from the smart key module.
“Emerg START” - Emergency Car Start by internal Emulating key 4A(HTAES) or 8H(DSTAES) with 1 of 10 saved car data files by “Read ECU & Open” function .
4. 5. “Add KEY” – Registering new Keys to Car. Erase Keys” – Erasing not required or lost end keys from car. “Sync ELV & IDC” – Synchronization of ELV and ID Code box with Smrt key module. This also repairing remote control synchronization when stop working after key programming.
6- “Open by CAN” – Open or close car function by can bus with 1 of 10 car data files.
7- “Read ECU PartNR”
* Function for read SMARTKEY module Part number without removing
Submenu “SYSTEM”:
1. “USB PC Link” – Running USB connection for Device updating .
2. “Device Info” – Device information – Serial Number, Version etc.
3. “Activations” – Information's about internal software activation.
4. “Battery Volt” – Voltage of internal battery used for device security.
5. “Format FLASH” – format internal flash disk – !!! IT ERASE ALL CAR DATA FILES !!!.
6. “USB MSD Disk” – Run USB MSD disk for see and/or copy/delete internal Car Data
Files.
